IMAGE ZOOMAt locations such as public housing, office, factory, etc. the vehicle crossings can be controlled by the automation of the sliding doors; standard motors produced based on the wing weight of the sliding doors are supplied as a set. Besides standard speed motors, special production very fast motors are also available. They have motherboards designed with micro-processor architecture compatible with all dry contact output. Sliding doors can be manufactured both with rails (rail sliding type) and without rails (floating type) by means of special sets. Passing safety can be ensured with photocell and detector. Flashing warning light indicates that the door is in motion.
Technical Specifications |
|
| Operating Voltage | AC 380V – AC 220V – DC 24V |
| ReverseVoltage Protectionfeature | Yes |
| Wide Operating Voltage Range | 360-400VAC - 200-240VAC 22-26V DC |
| Standby current | 1A @380VAC max. |
| AfeintCurrent | 4A @380VAC max. |
| Operating Temperature | -20°C +50°C |
| Button Type |
2-Button (Open / Close)
|
| Remote Control | Yes |
|
Warning Components |
Traffic Light , Strobe Light |
| Security Products |
Photocell, Loob Detector, RFID System, Fingerprint Password Device
|
| Programme Security | 100 Years |
| Error Prevention | Power-On-Reset |
| Bug Tracking Feature | Yes |
| Limit Switch Type |
nductive / NC / NO
|
| Auto Power Off Feature | Yes |
| Low Power Warning Feature | Yes |
| Over Current Protection | Yes |
| Motor Protection |
with Real Time Clock
|
| Opening / ClosingTime | 3-15 sec |
| Carrying Capacity | 300-5000 Kg |
| Slow/Start /Stop feature | Yes |
| Max Wing Length | 9 m |
